Fusion 2.5G PoE
เร็ว ๆ นี้Omada Fusion 2.5G PoE Gateway
- License‑Free Cloud Management for Multi‑Site Work
- Simplified Setup with App-Guided Onboarding via Bluetooth and One-Tap Bulk Device Adoption
- Enterprise‑Grade Performance: Quad-Core CPU, 9× 2.5G Ports, Up to 8‑WAN Load Balancing with Auto Failover, 8× PoE+ Ports with 110W Total Budget, 2.3 Gbps-Class IDS/IPS Throughput*
- Quick Troubleshooting via Touchscreen, Reducing On-Site Visits
- Secure Remote Network Access in One Click Away with Omada LightLink VPN
- Advanced Software Capabilities: App‑Based ACL, Auto QoS, Full Mesh SD-WAN, Content Filtering & Ad Blocking, DPI
- Flexible Mounting Options: Desktop, Wall-Mountable**, Rack-Mountable**
| Overview | |
|---|---|
| Built-In Omada OS Applications | Network Application |
| Managed Omada Devices | Recommended for up to 30 devices |
| Client Capacity | Recommended for up to 300 connected clients |
| Interface | • 1× 2.5G RJ45 WAN port• 8× 2.5G RJ45 LAN/WAN ports• 8× PoE+ ports, 110W Total Budget• Up to 4 simultaneous WAN ports |
| IPS Throughput | 2.3 Gbps |
| Site-to-Site VPN Throughput | 1,400+ Mbps† |
| Management | Cloud, local, and Omada App management |
| Mounting | • Desktop• Wall-mount (magnetic-mount plate sold separately)• Rack-mount (rackmount kit sold separately) |
| Dimensions | 8.9 × 5.3 × 1.24 in (226 × 135 × 31.5 mm) |
| Built-in Omada Controller§ | |
|---|---|
| Cloud Access | √ |
| Local Management | √ |
| Omada App | √ |
| Multi-Site Management | Via the Omada Cloud Management Platform |
| Restore & Backup | √ |
| Automatic Device Discovery | √ |
| Network Topology | √ |
| Dashboard | √ |
| Device List / Client List | √ |
| Logs / Alerts / Events | √ |
| Batch Firmware Upgrade | √ |
| Health Monitoring | √ |
| Internet Activity | √ |
| Captive Portal | √ |
| RADIUS / LDAP Authentication | √ |
| 802.1X Authentication | √ |
| OUI-Based VLAN | √ |
| Diagnostics Tools | Ping Test, Packet Capture, Terminal, Cable Test, Interference Detection, Remote Access, IntelliRecover, Port Mirroring |
| SNMP | v1/v2c/v3 |
| SECURITY | |
|---|---|
| IDS/IPS | √ |
| DPI | √ |
| Application-Based ACL | √ |
| Content Filtering | √ |
| Ad Blocker | √ |
| Safe Search | √ |
| DNS Security | √ |
| Firewall | √ |
| Attack Defense | √ |
| ARP Inspection | √ |
| VPN & SD-WAN | |
|---|---|
| Omada LightLink VPN | √ |
| Site-to-Site VPN | WireGuard VPN / IPsec VPN |
| VPN Server | WireGuard VPN / OpenVPN / IPsec VPN / SSL VPN / L2TP VPN / PPTP VPN |
| VPN Client | WireGuard VPN / OpenVPN / L2TP VPN / PPTP VPN |
| SD-WAN | Full Mesh Mode |
| VPN Throughput | • Omada LightLink VPN: 1,200+ Mbps• IPsec VPN: 1,400+ Mbps• WireGuard VPN: 1265 Mbps• OpenVPN: 405 Mbps• L2TP VPN: 1250 Mbps• PPTP VPN: 465 Mbps• SSL VPN: 505 Mbps |
| Networking | |
|---|---|
| WAN Connection | Static IP / Dynamic IP / PPPoE / PPTP / L2TP / MAP-E / DS-Lite |
| Multi-WAN Failover & Load Balancing | √ |
| DHCP Server | √ |
| VLAN Segmentation | √ |
| Bandwidth Control | √ |
| QoS | √ |
| Static Routing | √ |
| Policy Routing | √ |
| NAT | Port Forwarding / Virtual Server / DMZ / ALG / UPnP / One-to-One NAT / Disable NAT |
| Dynamic DNS | TP-Link DDNS, 3rd-party DDNS, custom DDNS |
| IPv6 | Static IP / SLAAC / DHCPv6 / PPPoE / 6to4 Tunnel / Pass-Through / Non-Address Mode |
| Bonjour / mDNS | √ |
| IGMP v2/v3 Proxy | √ |
| HARDWARE | |
|---|---|
| Touchscreen | 3.69-inch color LCM touchscreen |
| Button | Reset button |
| CPU | Quad-core ARM Cortex-A73 @ 1.8 GHz |
| Memory | 2 GB DDR4 |
| Storage | 64 Mbit NOR flash + 16 GB eMMC |
| Power Supply | 54V DC / 2.43A Adapter |
| PoE Budget | 110W |
| Max Power Consumption | 128.7W (With 110 W PD connected) |
| Enclosure | Polycarbonate |
| LED | Ethernet |
| Fan | √ |
| Net Weight | 1.61 lb (728 g) |
| Surge Protection | 4 kV surge protection |
| ESD Protection | ±8 kV (Air), ±4 kV (Contact) |
| Onboarding | Bluetooth or Ethernet |
| Certifications | CE, FCC, RoHS |
| Environment | • Operating Temperature: 14 °F to 104 °F (-10 °C to 40 °C)• Storage Temperature: -22 °F to 158 °F (-30 °C to 70 °C)• Operating Humidity: 10% to 90% RH, non-condensing• Storage Humidity: 5% to 90% RH, non-condensing |
*Actual throughput may vary depending on traffic conditions, enabled features, and network environment.
**Magnetic‑mount plate and rack‑mount kit are sold separately.
§Controller and management features may vary depending on connected Omada devices, software versions, and deployment modes.
† Performance data is based on IPsec VPN.
