Campus Series Switches

Campus Series Switches are designed for enterprises, campuses, and ISPs. Supporting 25G and 100G speed with a PoE budget of up to 1,534W. They feature physical stacking, and advanced Layer 3 capabilities for reliability and scalability.


	S7500-32C	S7500-48Y8C	S7500-24Y4C	S7500-48XF4C	S7500-26XF6Y	S6500-48MPP6Y	S6500-48M6Y	S6500-24MPP4Y	S6500-24M4Y	S6500-48GP6XF	S6500-48G6XF	S6500-24GP4XF	S6500-24G4XF
Total Port Count	32	56	28	52	32	54	54	28	28	54	54	28	28
Downlink Port	(32) 100G QSFP28 Ports	(48) 25G SFP28 Ports	(24) 25G SFP28 Ports	(48) 10G SFP+ Ports	(26) 10G SFP+ Ports	(48) 2.5G PoE++ Ports	(48) 2.5G Ports	(24) 2.5G PoE++ Ports	(24) 2.5G Ports	(48) GE PoE+ Ports	(48) GE Ports	(24) GE PoE+ Ports	(24) GE Ports
Uplink Port	-	(8) 100G QSFP28 Ports	(4) 100G QSFP28 Ports	(4) 100G QSFP28 Ports	(6) 25G SFP28 Ports	(6) 25G SFP28 Ports	(6) 25G SFP28 Ports	(4) 25G SFP28 Ports	(4) 25G SFP28 Ports	(6) 10G SFP+ Ports	(6) 10G SFP+ Ports	(4) 10G SFP+ Ports	(4) 10G SFP+ Ports
PoE Budget	-	-	-	-	-	Max 1,484W*	-	Max 1,534W*	-	Max 1,440W*	-	Max 720W*	-
Console Port	√	√	√	√	√	√	√	√	√	√	√	√	√
Management Port	√	√	√	√	√	√	√	√	√	√	√	√	√
Physical Stacking	√ (Max 12pcs)**	√ (Max 12pcs)**	√ (Max 12pcs)**	√ (Max 12pcs)**	√ (Max 12pcs)**	√ (Max 12pcs)**	√ (Max 12pcs)**	√ (Max 12pcs)**	√ (Max 12pcs)**	√ (Max 12pcs)**	√ (Max 12pcs)**	√ (Max 12pcs)**	√ (Max 12pcs)**
M-LAG	√	√	√	√	√	√	√	√	√	√	√	√	√
Power Redundancy	√ (Hot-swappable)	√ (Hot-swappable)	√ (Hot-swappable)	√ (Hot-swappable)	√ (Hot-swappable)	√ (Hot-swappable)	√ (Hot-swappable)	√ (Hot-swappable)	√ (Hot-swappable)	√ (Hot-swappable)	√ (Fixed)	√ (Hot-swappable)	√ (Fixed)

*The total PoE budget varies with the power supply modules.

**Supports 12 units of physical stacking in standalone mode.

Port Sayısı
1. 5-11
2. 16-20
3. 24-32
4. 48-54
Max Downlink Port Speed/Type
1. 10 Gb/s SFP+
2. 10 Gb/s RJ45
3. 2.5 Gb/s RJ45
4. 1 Gb/s SFP
5. 1 Gb/s RJ45
6. 100 Mb/s RJ45
Max Uplink Port Speed/Type
1. 25 Gb/s SFP28
2. 10 Gb/s SFP+
3. 10 Gb/s RJ45
4. 2.5 Gb/s RJ45
5. 1 Gb/s SFP
6. 1 Gb/s RJ45
7. 100 Mb/s RJ45
PoE Support
1. Yes
2. No
PoE Type / Max PoE Budget per Port
1. 802.3af/at PoE+ (30W)
2. 802.3af/at/bt PoE++ (60W)
3. 802.3af/at/bt PoE++ (90W)
PoE Port Sayısı
1. 4
2. 8
3. 16
4. 24
5. 48
Kullanım Türü
1. Masaüstü
2. Wall Mounting
3. Pole Mounting
4. Rackmountable
Cloud Centralized Management
1. Yes
2. No
Özellikler
1. Fiziksel Stacking
2. VRRP
3. OSPF
4. ERPS
5. PBR
6. PIM-SM/DM
7. Perpetual PoE
8. Fast PoE
9. Statik Yönlendirme
10. STP/RSTP/MSTP
11. ACL
12. 802.1x
13. CLI Configuration
14. SNMP
Surveillance-Related Features
1. VLAN
2. QoS
3. PoE Auto Recovery
4. 250m (820ft) PoE Transmission under Extend Mode
5. Port Isolation
6. Auto Loop Detection
7. Cable Test
8. Port Management for Remote Camera Reboot
9. Physical Surveillance DIP Switch
Special Hardware Design
1. Fanless Design
2. Redundant Power Supply (RPS)
3. Console Port
4. Outdoor
Special Filter
1. L3
2. Lite L3

Karşılaştırın
SG6428XHP

Campus

Omada 24-Port Gigabit Stackable L3 Managed PoE+ Switch with 4 10G Slots
24× Gigabit PoE+ Ports

4× 10 Gbps SFP+ Slots

Up to 720W total PoE budget

Stackable

Optional Dual Redundant Power Supplies

Centralized Cloud Management
Karşılaştırın
SG6654X

Campus

Omada 48-Port Gigabit Stackable L3 Managed Switch with 6 10G Slots
48× Gigabit RJ45 Ports

6× 10 Gbps SFP+ Slots

Stackable

Dual Redundant Power Supplies

Centralized Cloud Management
Karşılaştırın
SG6428X

Campus

Omada Campus 24-Port Gigabit Stackable L3 Managed Switch with 4× 10G Slots
24× Gigabit RJ45 Ports

4× 10 Gbps SFP+ Slots

Stackable

Dual Redundant Power Supplies

Centralized Cloud Management
Karşılaştırın
SG6654XHP

Campus

Omada Campus 48-Port Gigabit Stackable L3 Managed PoE+ Switch with 6× 10G Slots
48× Gigabit PoE+ Ports

6× 10 Gbps SFP+ Slots

Up to 1440W total PoE budget

Stackable

Optional Dual Redundant Power Supplies

Centralized Cloud Management
Karşılaştırın
SX6632YF

Campus

Omada Campus 26-Port 10G SFP+ Stackable L3 Managed Aggregation Switch with 6× 25G Slots
26× 10G SFP+ Slots

6× 10/25G SFP28 Slots

Stackable

Dual Redundant Power Supplies

Centralized Management
