Campus Series Switches
Campus Series Switches are designed for enterprises, campuses, and ISPs. Supporting 25G and 100G speed with a PoE budget of up to 1,534W. They feature physical stacking, and advanced Layer 3 capabilities for reliability and scalability.
 |
 |
 |
 |
 |
 |
 |
 |
|
|---|---|---|---|---|---|---|---|---|
|
|
||||||||
Total Port Count |
28 |
32 |
54 |
28 |
54 |
54 |
28 |
28 |
Downlink Port |
(24) 25G SFP28 Ports |
(26) 10G SFP+ Ports |
(48) 2.5 GbE PoE++ Ports |
(24) 2.5 GbE PoE++ Ports |
(48) GbE PoE+ Ports |
(48) GbE Ports |
(24) GbE PoE+ Ports |
(24) GbE Ports |
Uplink Port |
(4) 100G QSFP28 Ports |
(6) 25G SFP28 Ports |
(6) 25G SFP28 Ports |
(4) 25G SFP28 Ports |
(6) 10G SFP+ Ports |
(6) 10G SFP+ Ports |
(4) 10G SFP+ Ports |
(4) 10G SFP+ Ports |
PoE Budget |
- |
- |
Max 1,484W* |
Max 1,534W* |
Max 1,440W* |
- |
Max 720W* |
- |
Console Port |
√ |
√ |
√ |
√ |
√ |
√ |
√ |
√ |
Management Port |
√ |
√ |
√ |
√ |
√ |
√ |
√ |
√ |
Physical Stacking |
√ (Max 12pcs) |
√ (Max 12pcs) |
√ (Max 12pcs) |
√ (Max 12pcs) |
√ (Max 12pcs) |
√ (Max 12pcs) |
√ (Max 12pcs) |
√ (Max 12pcs) |
Power Redundancy |
√ (Hot-swappable) |
√ (Hot-swappable) |
√ (Hot-swappable) |
√ (Hot-swappable) |
√ (Hot-swappable) |
√ (Hot-swappable) |
√ (Hot-swappable) |
√ (Hot-swappable) |
Mounting |
Rackmount |
Rackmount |
Rackmount |
Rackmount |
Rackmount |
Rackmount |
Rackmount |
Rackmount |
*The total PoE budget varies with the power supply modules.
