Omada T8S4-4T
Coming SoonOmada 8MP Turret PoE Security Camera System with 4TB HDD, 4 Cameras with 16-Channel NVR
- 16 Channel NVR with 8 PoE+ Ports*
- 4× 8MP Full-Color PoE Turret Cameras
- Red & Blue Flashing Lights and Sirens
- Person/Vehicle/Pet Detection
- 24/7 Continuous Recording and Local Storage
- Effortless Installation with PoE+
- NVR with 4TB HDD Built-in (Expandable to 16 TB)
- Camera with All-Metal Housing, IP67 Weatherproof and IK08 Vandal-Proof
| CAMERA | |
|---|---|
| Image Sensor | 1/2.7” Progressive Scan CMOS |
| Shutter Speed | 1/3 to 1/10000 s |
| Aperture | F1.6 |
| Lens | 4 mm, Fixed Focal Lens, M12 |
| FOV | Horizontal FOV: 88°, Vertical FOV: 46°, Diagonal FOV: 105.4° |
| Minimum Illumination | 0.005 Lux; 0 Lux with IR/White Light |
| Day/Night Mechanism | IR Cut Filter |
| Day/Night Switch | Auto |
| White LED | • Quantity: 4• Range: 98 ft (30m) |
| IR LED | • Quantity: 4• Range: 98 ft (30 m)• Wavelength: 850nm |
| Illuminator On/Off Control | Auto/Always on/Always off |
| Max. Resolution | 3840 x 2160 (8MP) |
| Main Stream | • Frame Rate:50Hz: 25fps (3840x2160, 2560x1440, 2304x1296, 2048x1280,1920x1080)60Hz: 24fps (3840x2160, 2560x1440, 2304x1296, 2048x1280,1920x1080)• Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.If 120dB WDR is turned on, the frame rate can only support up to 20fps. |
| Sub-Stream | • Frame Rate：50Hz: 25fps (840x480,704x576,640x480, 640x360, 352x288, 320x240)60Hz: 24fps (840x480,704x576,640x480, 640x360, 352x288, 320x240)• Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.If 120dB WDR is turned on, the frame rate can only support up to 20fps. |
| Video Bit Rate | • Main Stream: 256 Kbps to 8192 Kbps• Sub-Stream: 64 Kbps to 1024 Kbps |
| Video Compression | • Main Stream: H.265+/H.265/H.264+/H.264• Sub-Stream: H.265/H.264 |
| Event | • Motion Detection (Person/Vehicle/Pet Detection)• Line-Crossing Detection• Intrusion Detection |
| Recording Modes | Event-Triggered Recording, Scheduled Recording, 24/7 Recording (Default) |
| Interface & Button | • Buit-in Microphone; Records Anything Going on within a 16.4ft (5m) Radius of the Camera• Buit-in Speaker• 1× RJ45 10/100Mbps Self-Adaptive Ethernet Port, PoE• 1× DC Port• Reset Button• Red & Blue Warning Lights• Buit-in Memory Card Slot, Support MicroSD Card, up to 521GB△ |
| Operating Temperature | -30 °C to 60 °C (-22 ℉ to 140 ℉) |
| Operating Humidity | 95% or Less (Non-Condensing) |
| Power Supply | • 12V DC/1A, Max. 12 W, 5.5 mm Coaxial Power Plug• PoE: 802.3af/at, Max. 12.5 W |
| Protection | • IP67 Weatherproof• IK08 Vandal Proof |
| Product Dimensions (L x W x H) | 4.4 × 4.4 × 3.5 in (112 × 112 × 88 mm) |
| Weight | • Gross Weght: 0.84 kg (1.85 lbs)• Net Weght: 0.5 kg (1.10 lbs) |
| NVR | |
|---|---|
| IP Video Input | 16-Channel* |
| Managed Cameras | • 16 (HD)• 16 (2K/5MP)• 12 (4K/8MP)• 8 (12MP)• 6 (16MP) |
| HDMI Output Resolution | 1 Channel, Resolution: 3840x2160/30Hz, 2560x1440/60Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz |
| VGA Output Resolution | 1 Channel, Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz |
| Video Compression | H.265+/H.265/H.264+/H.264 |
| Record Resolution | 16MP / 12MP / 8MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF/ QCIF |
| Synchronous Playback | 16-Channel |
| Decoding Capability | • 25fps:10-ch @ 2MP• 30fps:1-ch @ 16MP, 2-ch @ 8MP, 4-ch @ 5MP, 5-ch @ 4MP, 6-ch @ 3MP |
| Hard Disk | • 1× SATA Interface, Up to 16 TB Capacity• 1× 4TB HDD Preinstalled |
| PoE Budget | 115 W Available for All PoE+ Ports, 30 W Max per Port |
| External Interfaces | • 1× eSATA, Supports External Storage Devices up to 16TB• 1× HDMI Port• 1× VGA Port• 1× Front USB 2.0 Port, 1× Rear USB 3.0 Port• 1-ch RCA Audio Input (1.4 Vp-p, 10KΩ), 1-ch RCA Audio Output (2.8 Vp-p, 1KΩ)• 1× 10/100/1000 Mbps Self-Adaptive Ethernet Port• 1× DC Power Supply Port• 8× PoE+ Ports |
| Network Protocol | • UPnP (Plug and Play)• NTP (Network Timing)• SMTP• DNS• TCP/IP• UDP• ICMP• HTTP• HTTPS• DHCP• RTSP• SSL/TLS• RTP• IPv4 • ARP• LLDP• FTP • IPv6 • SNMP |
| Web Browser | • Chrome (57+)• Firefox (52+)• Edge (91+) |
| Max. User Access | 40 Users; Support up to 32 Simultaneous Video Streams |
| Power Supply | 53.5V DC/2.43 A |
| Working Temperature | • NVR: -10 °C to 55 °C (14 ℉ to 131 ℉）• Power Adapter: 0 °C to 40 °C (32 ℉ to 104 ℉) |
| Interoperability | ONVIF Profile G/S/T |
| Product Dimensions (L x W x H) | 10.2 × 9.1 × 1.8 in (260 × 230 × 45 mm) |
| Weight | • Net Weight: 1.86 Kg (4.1 lbs)• Gross Weght: 3.25 Kg (7.17 lbs) |
*The NVR's eight PoE ports support direct connection to eight wired cameras. To add eight more wired orwireless cameras, ensure all devices (NVR and cameras) are on the same LAN.
△The Micro SD card is not included in the package.
